Precision Tips for High Frequency Soldering Stations
Engineered for Quick 203/203H and compatible 203H-series high frequency soldering stations, these 200M series tips deliver rapid heat transfer and consistent performance for demanding soldering tasks. The 90W high frequency design provides ample thermal reserve for lead-free solder, multi-layer PCBs, and ground planes without significant temperature drops.
Material & Plating
Each tip features a C10200 oxygen-free copper core (oxygen content ≤ 0.001%) with thermal conductivity of approximately 380–400 W/(m·K). Formed by cold heading, the core offers about 15% higher thermal conductivity than machined alternatives, ensuring fast heat delivery to the joint.
The 72-hour nano-composite electroplating process applies four functional layers:
Iron layer (10 A/dm²): Dense crystalline structure for corrosion and wear resistance
Nickel layer (8 μm): Prevents rust and protects the copper base
Hard chromium layer (20 A/dm²): Maximizes oxidation resistance and prevents solder creep
Tin layer (12 μm): Pre-applied to the working end for immediate wettability
Performance & Compatibility
Long Service Life: Delivers 20,000–35,000 solder joints under standard conditions (350–400°C, proper maintenance). Actual lifespan depends on temperature, flux, and solder alloy.
Cost-Effective: Offers 30–50% savings compared to genuine Quick 200 series tips, with consistent quality across all batches.
Precision Fit: Outer diameter 4.0 mm, inner diameter 2.0 mm, total length approx. 31 mm – ensures secure contact with 203H-series heating elements.
Applications & Maintenance
Suitable for electronics repair, PCB assembly, and fine soldering of small components. These tips support both lead-free (SAC305) and leaded (Sn63Pb37) processes.
To extend tip life:
Clean with a damp sponge or brass wire ball during use.
Apply a solder "tin cap" before powering off.
Use recommended temperatures: 350°C ± 10°C for lead-free, 320°C ± 10°C for leaded solder.
Never use files or abrasives – these damage the plating.
Replace immediately if you observe:
Pits or holes on the working surface
Solder creeping up the barrel
Significant loss of heating efficiency
Permanent blackening that rejects solder
Bulk & Custom Orders
Volume discounts and custom tip shapes or plating specifications are available for qualified buyers. Contact us for technical datasheets or wholesale inquiries.
90W High Frequency Power: Matches your 203H station for rapid heat-up and intelligent temperature stability.
Precision Dimensions: 4.0mm outer diameter, 2.0mm inner diameter, 41mm total length – ideal for fine to medium electronics work.
Durable Construction: Crafted for long life and resistance to corrosion, even at high operating temperatures.
Universal Fit: Specifically engineered for seamless compatibility with 203H high-frequency soldering stations.
Professional Grade: Trusted by technicians and hobbyists who need repeatable, high-quality results.
Is this tip compatible only with the 203H station?
Yes, this 200M series tip is specifically engineered to fit 203H high-frequency soldering stations. Its 2.0mm inner diameter and 41mm length match the 203H’s heating element perfectly.
How can I confirm this is an authentic, high-frequency tip?
Authentic high-frequency tips, like this 90W high frequency soldering tip, are made with specialized alloys for rapid induction heating. Ordering directly from a professional soldering tip manufacturer like LinRising ensures you receive a genuine, performance-matched component.
What are the exact dimensions of this tip?
Outer diameter: 4.0mm, Inner diameter: 2.0mm, Total length: 41mm. These dimensions are designed for fine-pitch to general electronics assembly work.
How do I maintain this tip for maximum life?
Keep the tip tinned when the iron is idle. Use a damp cellulose sponge or brass wire cleaner to remove residue. Avoid aggressive files or abrasives. For optimal performance, use only with your 203H station and quality leaded or lead-free solder.
Can I get a custom soldering tip shape or size?
Yes. As a dedicated soldering tip manufacturer, we support custom orders for specific geometries, diameters, or lengths for volume buyers. Please contact our sales team with your specifications.
